Hotel Self-Service Information Kiosk Book self-service terminal
This kiosk is special design for hospital as healthy report
printing kiosk terminal. Euqipped with Magnetic card swiper, NFC
card reader, QR/Bacode scanner and A4 laser printer, the user could
check whether his report is finished via get his member card read
by NFC card reader and Magnetic card reader, and get report auto
printing via scanner the code he get.
For this kiosk model, camera, Wifi, 3g Route, keyboard and Pinpad
are available.
1.Durable 1.5-2.0mm steel sheel
2.Bill feeder/banknote dispenser
3.1 year warranty
4.20 working delivery day
5,FCC,CE
Specifications:
| Pc Configutation | Industrial Board | H110 |
| CPU | Intel Dual Core I3/I5/I7 |
| RAM | 4G/8G DDR4 2666 |
| HDD | 500G/1TB HDD |
| Interface | 10*COM(RS-232)Ports;1*LTP;14* USB Ports,2 10/100M Net Port
;Integrated Net Card, Sound Card |
| Monitor | Screen Size | 15/17 inch/19inch(other size optional) |
| Brightness | 350cd/m2 |
| angle | horizontal 100°above;Vertical 80°above |
| Contrast | 1000:1 |
| Backlight tube life | more than 40,000hours |
| Max. resolution | 1024*768/1280*1024 |
| Touch Screen | Screen Size | 15/17/19 inch Diagonal ( optional) |
| Resolution | 4096x4096 |
| Capacitive touchscreen with 10 touch points |
| High Transparence, high precision and durability,Orientation
precision< 2mm(0.080 inch);pure tempered glass;Single-point
touch Life expectancy more 50,000,000 times |
| Bank/Credit Card Reader ( optional) | Interface | RS232 |
| Card Type | Motorized/Dip : EMV proved Magcard/IC reader; Shutter(motorized);
Confiscate card(motorized) |
| Support Magcard, IC Card, RF Card, Mifare S50,S70,UL Card |
| Power Voltage | DC 24V±5% |
| Card Entry method | Magnetic signal, Optoelectronic signal and rear card signal |
| Encrypted Pinpad ( optional) | 3DES Metal EPP: 16bits, waterproof, dustproof, vandalproof |
| Keylift~span | 2,000,000 cycles |
| Key force | 2~3N |
| Key trip | >2.5mm |
| Protection level | ip65 |
| Cash Acceptor ( Optional) | Validation Rate | 96% or higher |
| Banknote Insertion | Four-way |
| Escrow | One banknote |
| Capacity | 1000 notes Max |
| Coin Acceptor ( optional) | Coin Acceptance | Max 32 coin types, in 2*16 or 1*32 channels |
| Detection ability of counterfeit Coins | with high detection ability of counterfeit coins |
| Accepting Speed | 2 Coins/Sec |
| Supply Voltage | 10V-16V DC |
| Epson Receipt /Custom Thermal Printer ( Optional) | Autocutter | included |
| Technology | Thermal printing |
| Paper width | 80mm |
| Printing speed | 150mm/s |
| Data buffer | 4KB |
| Cutter | Full/half cutter |
| Interface | RS232 ,USB |
| A4 laser printer | Color printer | Color printing ( double size printing for optional) |
| White & balck printer | Normally Recommand with HP/Brother |
| UPS ( optional) | Input voltage | 145-290va |
| Output voltage | 200-255va |
| Max time for supplying a single PC | 3~20minutes (for single PC) |
| Operation System | Windows xp or windows 7, copy version |
| Kiosk Cabinet | Durable steel frame, Slim and smart design; Easy to install and
operate; Moisture proof,Antirust,Anti-acid,Anti-dust,Static free,
have color and LOGO upon request. |
| Packing | Security Packing method with bubble foam and wooden case |
| Product Application |
|---|
Hotel / Supermarket Shopping Mall School / Entertainment Hospital | Goverment Service Centers Telecom / Library Banks / Real Estate Other Cousltation Places |
