Commercial display 32 43 49 55 60 inch floor stand touch screen ad
kiosk LCD advertising display board led digital signage totem
Specifications
Digital Signage Quotation sheet-Android Wi- Fi with Touch |
Model NO.: | KH-DS43 | KH-DS49 | KH-DS55-T | KH-DS65 |
Size | 43" | 49" | 55" | 65" |
OS Functions |
OS system | Android 7.1. |
Chipest | Rockchip RK3288 Quad-core processor |
RAM | 2G NAND-Flash 8GB |
Decoding resolution | Up to 1080P |
Play mode | cycle,insert and timing |
Networking support | Ethernet,Wi-Fi |
Video format | WMV,AVI,FLV,RM,RMVB,MPEG4,MPEG,TS,MP4 etc |
Picture format | BMP,JPG,JPEG,PNG,GIF. |
RTC timing clock | support |
Timing on & off | support |
OS update | USB update |
OSD | English/optional |
Multi-point Touch |
Touch Technology | Infrared Sensor or Capacitive |
Touch Points | 10 Points |
Picture/Display |
Panel | 43" | 49" | 55" | 65" |
Max resolution | 1920*1080 (pixels) |
Brightness (type)/(min) | 350cd/㎡ (typ.) |
Ratio (type)/(min) | 1200:1 (typ.) | 1200:1 (typ.) | 4000:1 (typ.) | 5000:1 (typ.) |
Chroma | |
Response time (ms) | 8ms(typ.) | 8ms(typ.) | 6.5ms(typ.) | 8ms(typ.) |
Viewing area(mm) | 941.184×529.416 | 1073.8×604 | 1209.6×680.4 | 1428.48×803.52 |
Viewing angle | 178°(H)/178°(V) |
Life time(type)/(min) | 30,000 hrs(typ.) |
Environment |
Working temperature | 0℃~40℃ |
Working humidity | 20%~85% RH/n-Condensing |
Storage temperature | -10℃~60℃ |
Storage humidity | 10%~60% RH/n-Condensing |
Max.display hour/day | 18 hours |
Power |
Power supply | 100-240V,50-60 Hz |
Power consumption (Watt) | ≤90W | ≤115W | ≤140W | ≤180W |
Audio frequency output | left and right channels Speaker 5W*2 |
Connectivity (I/O) |
Power connection | *1 |
HDMI | *1 |
RJ45 | *1 |
USB 2.0 | *1 |
ID and Material |
Housing Material | Aluminum frame+tempered glass+metal |
Housing colour | Black/white/Black+silver border |
Weight |
Net weight | 38kgs | 44.5kgs | 50.5kgs | 62.5kgs |
Gross weight | 42kgs | 49.5kgs | 55.5kgs | 69.5kgs |
Package dimension/Carton box |
dimension(mm) | 1825*153*679 | 1895*153*753 | 1945*153*830 | 2095*153*953 |
Accessary |
Antenna | *1 |
Remote Control | *1 |
Power Cord | *1 |
1.Q: For this model, which sizes is available from you?
A: Normally, we supply 32”, 43”, 49”, 55” and 65”. If customers
need others size, we also supply such as 21.5”, 75” 86”.
2.Q: Is this model can make touch screen?
A: Yes, normally we have 3 kinds of touch for options, IR touch,
capacitive touch and touch foil.
3.Q: May I know the thickness of it? I want it very slim?
A: The thickness we can supply from 2.1cm to 3.0cm depends on what
touch you choosing.
4.Q: If the customized do you support?
A: Yes, we can do OEM and ODM. we supplied different customized
service for customers, such as the color, camera, wheel, printer,
card reader and so on.
5.Q: Which OS do you supply?
A: Windows and Android. The Version depending on customers’ need.
6.Q: How long is the delivery time?
A: Normally about 5-15 working days for standard version. If
customized product, need about 15-20 working days.
7.Q:How about the warranty?
A: We supply 1-year free warranty. If customer need longer warranty
period, can extend 2 years or 3 years.
8.Q: What is the MOQ?
A: We supply 1pcs MOQ for testing and qualification.
9.Q: What package do you have?
A: Different kinds of package for options: Wooden case, Honey comb
case, Flight case.
